Year: 2012
Motors:
Bottom horizontal: 10 HP
Right vertical: 10 HP
Left vertical: 15 HP
Top horizontal: 15 HP
Top horizontal: 15 HP
Bottom horizontal: 15 HP
Universal head: 10 HP (1-1/4")
Feed drive: 10 HP (inverter controlled)
Feed speed: 6 ~ 36 m/min
Working capacity:
Minimum and maximum planing width: 10 mm ~ 230 mm
Minimum and maximum working thickness: 7 ~ 160 mm
Seven (7) spindles, 50 mm diameter
Features:
Chrome-plated table
Automatic table lubrication
Auxiliary rollers for short workpieces (1 set)
Infeed table drive rollers (1 set)
Outfeed table drive rollers (3 sets)
Noise reduction & safety guard
Digital feed system
Table with phenolic insert for the 2nd horizontal head
Pneumatic side pressure on the infeed table (before and after the safety guard)
Pneumatic pressure on vertical heads
Pneumatic cylinder chip breaker on top head
Mechanical digital readout system for top heads
Universal spindle with electric elevation system (inverter)
Spiral cutterheads: HD-A07
125 mm (D) x 40 mm (B) x 230 mm (L) x 6T x 4 pcs
125 mm (D) x 40 mm (B) x 125 mm (L) x 6T x 2 pcs
Net weight: 5500 kg / 12,100 lbs
